6306 Bearings Specifications:
| Product Name: | Deep groove ball bearings | Model: | 6306 bearings |
| Certification: | ISO9001-2015 | Country of origin: | Hebei province,China |
| Material: | Chrome steel | Structure: | Deep Groove |
| Type: | Ball Bearings | Bore Size:30 | mm |
| Model Number: | 6306 open,:6307ZZ,:6307 2rs | Precision Rating: | ABEC 1,ABEC 3,ABEC 5, ABEC 7 |
| Seals Type: | ZZ 2RS OPEN | Number of Row: | Single Row |
| Cage: | Steel Cage | Lubrication: | Oil or grease |
| Service: | OEM Service | Package: | Colorful box,White box,and plastic tube |
| Brand: | NSAR,3D,OWO,CBQ,NASA | Size: | 30X72X19MM |
| Products series: | Miniature ball bearings,such as 6306zz 6000 series ,such as 6004 bearing 6200 series,such as 6205 bearing 6300 series,such as 6305 bearing 6900 series,such as 6903 bearing |
Sample: | Available |
| (Kn)Basic LoadRating | (Kn)Basic LoadRating | (r/min)LimitRotational Speed | (r/min)LimitRotational Speed |
| Dynamic Cr | Static Cor | Grease Lubrication |
Oil Lubrication |
| 27 | 15.19 | 8500 | 11000 |
| Weight | |||
| 0.3498 |
6306 bearings technical reference:
Internal Clearances Radial Ball Bearings
In the manufacture of ball bearings,it is standard practice to assemble rings and balls with a specified internal clearance. This characteristic is necessary to absorb the effect of press fitting the bearing rings at mounting.Internal clearances sometimes are utilized to compensate for thermal expansion of bearings, shafts and housings orto provide a contact angle in the bearing after mounting.Internal clearance can be measured either by gauging radially or axially.
Radial measurement is accepted as the more significant characteristic because it is more directly related to shaft and housing fits.
Radial lnternal Clearance
The radial internal clearance of a radial contact ball bearing can be defined as the average outer ring raceway diameter minus the average inner ring raceway dianer minus twice the ball diameter Radial internal clearance can be measured mechanically by moving the outer ring horizontally as pictured in Figure 1. The total movement of the outer ring when the balls are properly seated in the raceways determines the radial internal clearance.Several readings should be taken using different circumferential orientations of the rings in order to get a comprehensive average reading.
As a 6306 bearings manufacturer, NSAR wholesale 6306 deep groove ball bearing for automobiles, medical equipment, sports machinery, textile machinery,agricultural machinery and electrical tools. Factory-price, high-quality 6306 bearing for sale, and support custom 6306 bearings. Order best deep groove ball bearings in bulk from NSAR to boom your 6306 bearing business to a new level!
