6016 Bearing Specifications:
6016 deep groove ball bearing specification
| Deep Groove Ball Bearings No. | I.D | O.D | B | |||
| d | d | Open type | ||||
| mm | inch | mm | inch | mm | inch | |
| 6016 | 80 | 3.1496 | 125 | 4.9213 | 22 | 0.8661 |
| Deep Groove Ball Bearings No. | B | Load Rating(KN) | Steel Ball Parameter | |||
| Closed type | Dynamic | Static | No. | Size | ||
| mm | inch | Cr | Cor | mm | ||
| 6016 | 22 | 0.8661 | 47.50 | 40.00 | 14 | 13.494 |
| Deep Groove Ball Bearings No. | Max speed | Weight Kg | ||||
| Grease | Oil | |||||
| r/min | r/min | |||||
| 6016 | 5300 | 6200 | 0.850 | |||
6016 Deep Groove Ball Bearings Maintenance and Safekeeping:
Maintenance
In order for the bearing to fully exert its performance and maintain its performance for a long time, regular maintenance (regular inspection) must be carried out.
Through appropriate regular inspections, it is very important to detect faults early and prevent accidents before they occur, which is very important for improving productivity and economy.
Safekeeping
Bearings are coated with an appropriate amount of anti-rust oil and packaged with anti-rust paper when they leave the factory. As long as the packaging is not damaged, the quality of the bearings will be guaranteed.
However, for long-term storage, it is advisable to store it on a shelf 30cm above the ground under conditions where the humidity is less than 65% and the temperature is about 20°C. In addition, the storage location should be away from direct sunlight or contact with cold walls.
NSAR premium 6016 bearing is made in China and 6016 bearings Made of bearings steel,bearings steel with higher and more uniform hardness and abrasion resistance.The most rare is that of bearings steel with ultra-high hardness at the same time,have very strong elasticity.The assurance of hardness can prolong the service life of bearings.
